Tiller Gasoline Engine
Displacement and Fuel Tank: Displacement varies by engine power, while fuel tank capacity typically ranges from 1.5 liters to 3.6 liters.
The gasoline engine for tillers is a gasoline-powered engine used to drive tillers in performing tillage tasks.
Power and Models: Common power ranges from 4.5HP to 7.5HP, with power output at 6.5HP/3600r/min. Some models also feature the 7.5HP 170F/P engine.
Displacement and Fuel Tank: Displacement varies by engine power, while fuel tank capacity typically ranges from 1.5 liters to 3.6 liters.
Cooling and Starting: Generally employing air-cooling systems, eliminating the need for complex water-cooling equipment. Common starting methods include recoil starter operation, where manual pulling of the starter cord drives the engine to ignite.
Versatile Functionality: Leveraging its power output and compatible attachments, it can perform over 40 field operations including trenching, ridge formation, hilling, rotary tilling, weeding, and fertilizing, meeting diverse agricultural production needs.
User-Friendly Operation: Most tiller gasoline engines feature handlebar clutches and throttle cable speed control. Ergonomically designed control levers allow operators to manage clutch engagement and speed adjustment with simple handlebar movements. Additionally, some models incorporate differential steering systems, enabling directional changes via a rotary knob-significantly reducing operational complexity.
Products parameter
| Tiller Gasoline Engine | |||||||
| Model | BoreStroke(mm) | Displacement(cc) | Engine Speed(rpm) | Rated AC Output (kw) | Fuel Tank Capacity(L) | Engine Oil Capacity(L) | Fuel Consumption(g/kw.h) |
| 170F | 70*54 | 208 | 3600 | 4 | 3.6 | 0.6 | 395 |
| 177F | 77*58 | 270 | 3600 | 4.5 | 6.5 | 1 | 370 |
| 190F | 90*66 | 420 | 3600 | 8.2 | 6.5 | 1.1 | 370 |
| 192F | 92*66 | 440 | 3600 | 9 | 6.5 | 1.1 | 370 |
| 196F | 96*86 | 622 | 3600 | 13 | 6.5 | 1.6 | 390 |
| Our Entire Product Series Supports Customized Solutions. Parameters Can Be Optimized To Meet Your Specific Requirements | |||||||
Product Details
Widely Applicable
Product compatibility covers a wide range of applications:
1. Agricultural machinery (micro tillers/sprayers/seeders/fertilizer spreaders/lawn mowers/brush cutters/threshing machines/combine harvesters) .etc
2. Non-agricultural equipment compatibility (small concrete vibrators/portable generators/landscape shredders/high-pressure washers/small air compressors/construction mud pumps/emergency drainage pumps). etc.
Why do We Choose Lomarch?
- Dual-shaft diameter + quick-release interface, compatible with over 20 types of small and medium-sized equipment without modification.
- Fuel consumption is 10%-12% lower than comparable horsepower engines, delivering over 5 hours of runtime on a full tank.
- Accessories are universally compatible and readily available, with basic maintenance manageable by users themselves.
- Fuel consumption is 10%-12% lower than comparable horsepower engines, with a full tank lasting over 5 hours.
